CWF Custom Micro Click Flashlight - Stonewashed Titanium

• Pineapple Mini Flashlight
• 2 Spare O-rings
• Optional Metal Ring (alternative to pocket clip)
• 1 x AAA 10440 Rechargeable Battery (installed)

A forward click switch (included on the ReyLight Pineapple Mini MKII flashlights) allows you to press halfway for momentary activation and fully click to lock the light on. This is useful for quick bursts of light without fully engaging the switch.

A reverse click switch requires a full press to turn the light on. Once on, you can cycle through modes. It does not support momentary activation.

What’s the main difference between the two?

• Forward Click: Press halfway for momentary light, fully click to stay on.

• Reverse Click: Requires a full click to turn on, no momentary function.

No.

Unscrew the flashlight and place the included battery inside.

Full Click = Toggles Power

Half Click = Toggles Brightness

To charge the light, you'll need to take the battery out and place it into a 10440 compatible charger (sold separately).

If you need a charger, we suggest this one:

Battery Charger for CWF Flashlights

Micro Lights use the Chimera driver and programming is as follows:

Mode Groups:

1. Moonlight, 5%, 15%, 35%, 50%, 100%
2. Moonlight, 15%, 50%, 100%
3. 5%, 15%, 35%, 100%
4. 15%, 100%
5. 5%, 15%, 35%, 50%, 100%
6. 50%

Reversing Options/Bonus Utility Modes (0.5 second press):

• Turbo
• Strobe
• Battery Check (1–8 blinks; 8 = full)
• Bike Indicator Strobe(Note: Reversing can be toggled on or off in configuration mode – Option 5)

Configuration Instructions:

1. Quickly turn the light off and on 15 or more times until it begins flashing – this enters configuration mode.
2. The light will emit 1 to 5 solid flashes. Each number corresponds to one of the configuration options listed below.
3. After the solid flashes, the light will begin to strobe. Turn the light off and on during the strobing phase to select that option.
4. For Option 1 (Mode Group Select), the light will then flash 1 to 8 times. Turn the light off and on after the number of the group you want.
5. For Option 4 (Temperature Calibration), the light will ramp up to turbo – turn it off when it reaches your desired temperature.

Configuration Options:

1. Mode Group Select
2. Memory Toggle (on/off)
3. Mode Order Toggle (high-to-low or low-to-high)
4. Temperature Calibration Mode
5. Reversing Toggle
